부품 정보
Filled with molybdenum disulfide
MRC:
The process used in manufacturing the item.AARN
Fabrication Method:
Extruded
MRC:
A numeric value that reflects the hardness of a nonmetallic item when used in conjunction with a hardness rating scale.AASF
Nonmetallic Hardness Rating:
118.0 rockwell r
MRC:
The maximum load in tension applied in a longitudinal direction,per unit of cross-sectional area,that the material can withstand without rupture.AASH
Min. Tensile Strength (psi):
11000 pounds per square inch
MRC:
A measurement taken at right angles to the length of an item,in distinction from thickness.ABGL
Width:
12.000 inches
MRC:
A measurement of the smallest dimension of an item,in distinction from length or width.ABNM
Thickness:
0.031 inches
MRC:
A measurement of the longest dimension of any object,in distinction from width.ABRY
Length:
12.000 inches
MRC:
The ability of the material to transmit light and allow visual perception.ABWN
Material Transparency:
Opaque
MRC:
The maximum load which can be applied normally to the plane of the material,per unit of cross-sectional area,that an item can withstand without fracture.ADZB
Flexural Strength:
Not rated
MRC:
A characteristic of light that can be specified in terms of luminance,dominant wavelength,and purity.HUES
Color:
Black or gray
MRC:
The element,compound,or mixture of which an item is fabricated,excluding any surface treatment.MATL
Material:
Plastic, polyamide, polyhexamethylene adipamide, l-p-410
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Plastic polyhexamethylene adipamide
MRC:
The specification,standard,or manufacturers reference,and the classification designation,such as class,condition,temper,and the like,that identifies the material.MDCL
Material Specification:
L-p-410 federal specification 1st material response
MRC:
A feature of the item of supply which must be specifically recorded when the reference number covers a range of items.ZZZY
Reference Number Differentiating Characteristics:
As differentiated by length, width and thickness
