MRC:
The dimension measured along the longitudinal axis with terminated points at the extreme ends of the item.ABHP
Overall Length:
72.000 inches
MRC:
A measurement of the smallest dimension of the material,in distinction from length or width.ABPX
Material Thickness:
Between 0.044 inches and 0.056 inches
MRC:
The length of a straight line which passes through the center of a pin,and terminates at the circumference.ABVV
Pin Diameter:
0.090 inches
MRC:
Indicates the performance capability of the item or component.AGLD
Performance Type:
Not rated
MRC:
An indication of whether or not a reversible feature is included.AJNC
Reversible Feature:
Not included
MRC:
Indicates the type of hinge which permits either mortise or surface mounting.AKER
Hinge Mounting Type:
Full surface
MRC:
An indication of whether or not the pin is removable.AKES
Pin Removability:
Removable
MRC:
An indication of whether or not a rising pin is included.AKET
Rising Pin:
Not included
Pin Center To Body Edge Distance:
1.375 inches
MRC:
Indicates the type of cylindrical projection through which an axis or pin passes.AKNB
Knuckle Type:
Friction
MRC:
The element,compound,or mixture of which the item is fabricated,excluding any surface treatment,and its location.ANNQ
Material And Location:
Aluminum alloy, qq-a-200/3, alloy 2024, t3511
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the item.STYL
Style Designator:
Butt
MRC:
The specification,standard,drawing,or similar instrument that specifies environmental and performance requirements or test conditions under which an item is tested and establishes acceptable limits within which the item must conform identified by an alphabetic and/or numeric reference number. includes the commercial and government entity (cage) code of the entity controlling the instrument.TEST
Test Data Document:
96906-ms20001 standard (includes industry or association standards, individual manufactureer standards, etc.).
MRC:
The document designator of the specification or standard which established the item of supply.ZZZK
Specification Data:
96906-ms20001-10 government standard
