부품 정보
Maxium recommended temperature is 450 degrees fahrenheit
MRC:
Indicates the type of hole/s/ in the tongue.AAAL
Tongue Hole Type:
Round, unthreaded
MRC:
An overall measurement taken at right angles to the length of an item,in distinction from thickness.ABMK
Overall Width:
Between 0.365 inches and 0.385 inches
MRC:
The length of a straight line which passes through the center of a circular figure or body,and terminates at the circumference.ABMZ
Diameter:
Between 0.109 inches and 0.209 inches
MRC:
A measurement of the smallest dimension of the material,in distinction from length or width.ABPX
Material Thickness:
0.032 inches
MRC:
The national stock number or the identification information of the end equipment for which the item is a part.AGAV
End Application:
Rq-4a
Center To Center Distance Between Loop And Mounting Hole:
0.623 inches
Distance From Loop Center To Tongue End:
0.811 inches
MRC:
The length of a straight line which passes through the center of the loop,and terminates at the inside circumference.BZTN
Loop Inside Diameter:
Between 0.423 inches and 0.453 inches
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Rubber fluorosilicone class fq cushion
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Stainless steel band
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the item.STYL
Style Designator:
Single loop
