묘사:
Fluid Passage Bolt
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the body.AAQL
Body Style:
Body wrenching
Concentric Hole Diameter:
0.172 inches
MRC:
The dimension measured along the longitudinal axis with terminated points at the extreme ends of the item.ABHP
Overall Length:
1.922 inches
MRC:
A narrative description of the type of end connection.ACKM
First End Connection Type:
Threaded external tube
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the end.ACKN
First End Style Designator:
Flared
MRC:
A numeric-alpha designator indicating the pitch diameter tolerance and an external or internal thread.ACLK
First End Thread Class:
3a
MRC:
The direction of the thread when viewed axially. a right-hand thread winds in a clockwise direction while a left-hand thread winds in a counterclockwise direction.ACLL
First End Thread Direction:
Right-hand
MRC:
A narrative description of the type of end connection.ACLS
Second End Connection Type:
Threaded external tube
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the end.ACLT
Second End Style Designator:
Flared
MRC:
A numeric-alpha designator indicating the pitch diameter tolerance and an external or internal thread.ACMR
Second End Thread Class:
3a
MRC:
The direction of the thread when viewed axially. a right-hand thread winds in a clockwise direction while a left-hand thread winds in a counterclockwise direction.ACMS
Second End Thread Direction:
Right-hand
MRC:
The national stock number or the identification information of the end equipment for which the item is a part.AGAV
End Application:
Aircraft application
MRC:
The shortest straight line between flats,perpendicular to the height.ASDB
Width Across Flats:
0.688 inches
MRC:
A measurement of the extent of threads,including incomplete threads,along a line parallel to the longitudinal thread axis.ATKZ
First End Thread Length:
0.437 inches
MRC:
A measurement of the extent of threads,including incomplete threads,along a line parallel to the longitudinal thread axis.ATLF
Second End Thread Length:
0.550 inches
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the wrenching feature.BBDF
Wrenching Feature Style:
Hexagon
First Diameter From Wrenching Feature:
0.435 inches
Length From Bearing Surface Of Wrenching Feature To End Of First Diameter:
0.750 inches
First Radial Fluid Hole Diameter:
0.188 inches
Distance From First Radial Hole Center To End Of Bolt:
0.781 inches
Length From Bearing Surface Of Wrenching Feature To Bolt End:
1.188 inches
Wrenching Feature Height:
0.184 inches
MRC:
A designator distinguishing one group of thread diameter-pitch combinations from another by the number of threads per measurement scale for a specific diameter.CQMM
First End Thread Series Designator:
Unf
MRC:
The angle of the end surface upon which the mated surface seats.CQPR
First End Seat Angle:
45.0 degrees
MRC:
The designation which is used for the purpose of general identification of the nominal thread size.CQYM
First End Thread Size:
0.438 inches
MRC:
The angle of the end surface upon which the mated surface seats.CRCN
Second End Seat Angle:
37.0 degrees
MRC:
The designation which is used for the purpose of general identification of the nominal thread size.CRNB
Second End Thread Size:
0.438 inches
MRC:
A designator distinguishing one group of thread diameter-pitch combinations from another by the number of threads per measurement scale for a specific diameter.CRPF
Second End Thread Series Designator:
Unf
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Steel comp 304
MRC:
The specification,standard,or manufacturers reference,and the classification designation,such as class,condition,temper,and the like,that identifies the material.MDCL
Material Specification:
66 federal standard single material response
MRC:
The metallic,nonmetallic,and/or chemical properties with which the item is plated,dipped,and/or coated.the treatment is designed to protect the surface(s) and cannot be wiped off.SFTT
Surface Treatment:
Passivate
MRC:
The document designator of the specification or standard which established the item of supply.ZZZK
Specification Data:
88044-an774 government standard and 81343-as4875/1 professional/industrial association standard
