부품 번호 AC3258-68H2

Fluid Filter

가격 및 가용성

이 NSN의 현재 가격 및 가용성에 대해 이 양식을 제출하십시오.
부품 번호:
양:
이메일 주소:
전화:
참조:
회사:
이름:

우리는 귀하의 정보를 누구에게도 공유하거나 판매하지 않습니다.
사생활 | 용어

All major credit cards accepted as well as gov. p-cards

이 제품의 과거 가격은 2845.7 and 3721.3 USD. 수량, 가용성, 상태, 리드 타임 및 품목 중단 가능성에 따라 최신 견적을 제공할 때까지 가격을 보장할 수 없습니다.

부품 번호
비무장화
수명
UOM
NIIN
부품 번호:
ac3258-68h2
비무장화:
Yes - DEMIL/MLI
수명:
N/A
측정 단위:
No qup EA
NIIN:
002255610
NSN
국가 주식 번호:
1650-00-225-5610 1650002255610
TXT
묘사:
Fluid Filter
INC
INC
아이템 이름 코드:
32622
INC
COM
컴플라이언스:
MRC:
Indicates the type of mount utilized to support the item.AAXX
Mounting Type:
Strap head
MRC:
A measurement of the longest dimension of the body,in distinction from width.ADAQ
Body Length:
6.765 inches
MRC:
A measurement taken at right angles to the length of the body,in distinction from thickness.ADAT
Body Width:
2.750 inches
MRC:
A measurement from the bottom to the top of the body,in distinction from depth.ADAU
Body Height:
1.832 inches
MRC:
The size of the smallest particle which the element is capable of removing from the fluid which passes through the filtering material.ADNH
Filtration Rating In Microns:
15.0
MRC:
Indicates the design type of the item.APGF
Design Type:
Reusable
MRC:
The number of filtering elements provided.CCZM
Filtering Element Quantity:
1
MRC:
The maximum pressure at which the item is rated for operation.CQGM
Maximum Operating Pressure:
3000.0 pounds per square inch
MRC:
An indication of the structure or characteristic of the filtering media.CRXW
Filtering Media Design:
Corrugated single filtering media response
MRC:
Indicates the type of connection on the first intake.CRXZ
First Intake Connection Type:
Threaded internal tube side
MRC:
Indicates the first discharge connection relationship to an intake connection.CSJR
First Discharge Connection Relationship To Intake Connection:
Identical to first intake connection
MRC:
A designation distinguishing one group of thread diameter-pitch combination from another by the number of threads per measurement scale for a specific diameter.CTDY
First Intake Thread Series Designator:
Unf
MRC:
A designation that is used for the purpose of general identification of the thread.CTGK
First Intake Thread Size:
0.562 inches
MRC:
A numeric-alpha designator indicating the pitch diameter tolerance and an external or internal thread.CWNZ
First Intake Thread Class:
3b
MRC:
The direction of the thread when viewed axially.a right-hand thread winds in a clockwise direction while a left-hand thread winds in a counterclockwise direction.CXPF
First Intake Thread Direction:
Right-hand
MRC:
The filtering system for which the item is designed to be used.CXZX
Filtering System For Which Designed:
By-pass flow
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Aluminum alloy sediment bowl
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Stainless steel filtering medium
MRC:
The justification for the assignment of a federal supply class /fsc/ to an item based on the classification of the next higher classifiable assembly.ZZZV
Fsc Application Data:
Hydraulic system, aircraft
