부품 정보
Flange provided with 8 grooves
MRC:
The dimension measured along the longitudinal axis with terminated points at the extreme ends of the item.ABHP
Overall Length:
Between 0.9140 inches and 0.9240 inches
MRC:
The length of a straight line which passes through the center of the body,and terminates at the outside circumference.ADAR
Body Outside Diameter:
Between 3.4550 inches and 3.4560 inches
MRC:
The length of a straight line which passes through the center of a body,and terminates at the inside circumference.ADAS
Body Inside Diameter:
Between 3.3430 inches and 3.3460 inches
MRC:
The element,compound,or mixture with which the item is lubricated.ADZG
Lubrication Material:
Lubricating oil
MRC:
The length of a straight line which passes through the center of the flange,and terminates at the outside circumference.AEPR
Flange Outside Diameter:
Between 4.6150 inches and 4.6350 inches
MRC:
A measurement taken at right angles to the length of a flange,in distinction from thickness.AGFF
Flange Width:
Between 0.1100 inches and 0.1150 inches
MRC:
The style designation indicating the configuration that most nearly corresponds to the means whereby the lubricant is set into the item.AGKH
Lubricant Accommodation Style:
Grooved closed both ends
MRC:
The physical configuration of the corner.BZLX
Corner Shape:
Chamfered inside left corner
MRC:
The physical configuration of the corner.BZLX
Corner Shape:
Chamfered outside right corner
MRC:
The physical configuration of the corner.BZLX
Corner Shape:
Square inside right corner
MRC:
The physical configuration of the corner.BZLX
Corner Shape:
Square left flange body corner
MRC:
The physical configuration of the corner.BZLX
Corner Shape:
Square left flange outside right corner
MRC:
The physical configuration of the corner.BZLX
Corner Shape:
Square outside left corner
MRC:
Indicates the location and number of grooves on the surface of the item.CTMQ
Surface Groove Location And Quantity:
1 internal
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Lead alloy inner layer or tin alloy inner layer
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Steel comp 1010 outer layer or steel comp 1020 outer layer
MRC:
The specification,standard,or manufacturers reference,and the classification designation,such as class,condition,temper,and the like,that identifies the material.MDCL
Material Specification:
Mil-b-13506, comp 19 military specification 2nd material response inner layer
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the item.STYL
Style Designator:
22c solid, external flange one end
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the item.STYL
Style Designator:
Solid, external flange one end
